The most complete tips for aluminum profile shield selection and baffle
August 18,2021
There are many specifications of aluminum profiles. Which profile should be used to make the shield frame? In fact, this problem is very difficult for many novices, but it is very simple for the technical staff of the aluminum profile factory. We will help you choose suitable profile specifications according to their actual needs.
Tips for aluminum profile shield selection
The main basis for the selection of aluminum profile shields is load-bearing. Smaller-size profiles should be selected for small load-bearing, and large-size profiles should be selected for heavier load-bearing. Generally, if the load is about 200 kg, you can choose 3030 profile; for 400 kg, you can choose 4040 profile or 4080 profile; for 800 kg, you can choose 6060 profile or 8080 profile.
OEM Profile X 8 30x30
If you need to bear about 200 kg, you can choose our OEM Profile X 8 30x30, which help you better load-bearing lightweight walking cane with large quantity, or bulk motorcycle connecting rod kit.
OEM profile 8 40x40
4040 is divided into national standard and European standard, and is divided into 1.5 thickness and 2.0 thickness. How to choose? In fact, there is a formula for calculating the amount of deformation. According to this formula, it is easy to calculate the amount of deformation of the aluminum profile under its own weight and force. The amount of deformation must be controlled within a certain range, otherwise it will be bent or broken. . According to this amount of deformation, it is easy to know which specification to choose and the specific connection method to be used.
Different factories need to make frames to store some things, such as bulk belnding gloves, adl raw material for diaper, patch fitting, slate heart photo frame or others. If you want to use aluminum profiles to make frames, the aluminum profile factory uses 4040 aluminum profiles. , 4080 aluminum profile is used as the cabinet frame, which can be cut and assembled as required. Realize DIY and meet hands-on ability.
Misunderstanding
The thicker the wall thickness of the profile, the better or the larger the profile specification, the better? In fact, this is not the case. Before choosing, the technical staff will give opinions and suggestions, and everyone must listen to it. You cannot choose blindly. Otherwise, the cost will increase a lot and burden the company's investment.
After you understand how to choose the model of the aluminum profile shield, the following will share its baffle selection tips for you.
Selection tips for the baffle of the aluminum profile shield
As a protection device for mechanical equipment, aluminum profile shield can play a warning role, maintain the normal operation of the machine, protect the personal safety of workers, and increase the aesthetics of the mechanical equipment. The daily use of the shield frame is not a bare aluminum profile frame, and various baffles need to be installed on it to be truly effective. So how to choose the baffle of the aluminum profile shield?
1. Ordinary shield baffles are generally composed of mesh grids, which can play a good role in heat dissipation. The baffle composed of grid mesh is cheap and easy to install. Generally, it is directly fixed by pressing strips, which is strong and beautiful. General robots and other equipment like to use yellow sprayed grid mesh as the baffle, which not only protects the machine but also serves as a warning, keeping the workshop personnel away from the robot's operation and reducing accidental injuries.
2. If you have a little requirement for the shield, you can choose acrylic sheet or aluminum-plastic sheet as the baffle. Acrylic panels have many colors to choose from, such as transparent, brown, brown, etc., which can achieve different functions of the shield. For example, the transparent acrylic panel can clearly observe the operation of mechanical equipment. The brown acrylic panel has a good The role of shading and confidentiality. If the aluminum-plastic board is used as the baffle, the protective cover is equivalent to a dust-proof sealing cover, reducing the entry of dust, and at the same time, it can isolate the noise.
3. The shield baffle is made of aluminum alloy plate. The aluminum alloy plate has high hardness, elegant appearance, and its anti-collision performance is much better than that of mesh and acrylic plates. Of course, the price is higher than other materials. Generally, when large-scale equipment operations require high environmental requirements, aluminum alloy plates can only be selected.
Extra knowledge
|
OEM means original equipment manufacturer.
OEM is a fixed-point production, also commonly known as a foundry. It uses the key core technology that it has mastered to help brand owners be responsible for designing and developing new products and controlling sales channels.
OEM benefits
Companies that have been OEMs have also developed under the drive of the company, which fully embodies the principle of rational allocation of resources.
Operating in an OEM manner can more effectively allocate the limited internal resources of the enterprise, minimize the level of management, and improve the efficiency of operation and management.
|
CHOOAL is a reliable aluminum profile factory supporting OEM service. If you need OEM Profile X 8 30x30, OEM profile 8 40x40 or customization, welcome to contact us.
